DMF-Y-25 1 Inch BFEC Embedded Pulse Jet Valve For Dust Collector 24V DC 220V AC

Name: DMFY25 1 Inch BFEC Embedded Pulse Jet Valve For Dust Collector 24V DC 220V AC
Brand: Brando
Price: 1 USD

Wholesale DMF-Y-25 1 Inch BFEC Embedded Pulse Jet Valve For Dust Collector 24V DC 220V AC from china suppliers

Brand Name : Brando

Model Number : DMF-Y-25

Certification : CE

Place of Origin : China

MOQ : 1

Price : Negotiation

Payment Terms : L/C, T/T, Western Union, Paypal, MoneyGram

Supply Ability : 100000 pcs per month

Delivery Time : Negotiation

Packaging Details : Inner Box, Carton, Pallet

Product Name : DMF-Y-25 Pulse Jet Valve

Remote or Integral Pilot : Integral Pilot

Outlet Pipe Size : 1''

Structure : Diaphragm

Diaphragm Material : NBR (Buna)

Right Angle Pulse Jet Valve : DMF-Z-20, DMF-Z-25, DMF-Z-40S, DMF-Z-50S, DMF-Z-62S, DMF-Z-76S, DMF-Z-102S

Quick Mount Pulse Jet Valve : DMF-ZM-20, DMF-ZM-25, DMF-ZM-40S, DMF-ZL-B

Embedded/Immersion Pulse Jet Valve : DMF-Y-25, DMF-Y-40S, DMF-Y-50S, DMF-Y-62S, DMF-Y-76S, DMF-YA-76S, DMF-YB-76S, DMF-Y-102S, DMF-Y-102SA, DMF-Y-102SE

Flanged Pulse Jet Valve : DMF-ZF-25, DMF-ZF-40S

Straight Through Pulse Jet Valve : DMF-T-20, DMF-T-25S, DMF-T-40S, DMF-T-50S, DMF-T-62S

Working Pressure Range : 0.1 to 0.8MPa

Voltage : 24VDC, 220VAC

Contact Now

DMF-Y-25 1 Inch BFEC Embedded Pulse Jet Valve For Dust Collector 24V DC 220V AC

DMF Series BFEC Pulse Jet Valves:

1. Right Angle Pulse Jet Valve: DMF-Z-20, DMF-Z-25, DMF-Z-40S, DMF-Z-50S, DMF-Z-62S, DMF-Z-76S, DMF-Z-102S

2. Quick Mount Pulse Jet Valve: DMF-ZM-20, DMF-ZM-25, DMF-ZM-40S, DMF-ZL-B

3. Immersion (Embedded) Pulse Jet Valve: DMF-Y-25, DMF-Y-40S, DMF-Y-50S, DMF-Y-62S, DMF-Y-76S, DMF-YA-76S, DMF-YB-76S, DMF-Y-102S, DMF-Y-102SA, DMF-Y-102SE

4. Flanged Pulse Jet Valve: DMF-ZF-25, DMF-ZF-40S

5. Straight Through Pulse Jet Valve: DMF-T-20, DMF-T-25S, DMF-T-40S, DMF-T-50S, DMF-T-62S

Main Dimension of DMF-Y-25 Pulse Jet Valve:

DMF-Y-25 1 Inch BFEC Embedded Pulse Jet Valve For Dust Collector 24V DC 220V AC

Technical data of DMF Series Embedded Pulse Jet Valve:

Model number	DMF-Y-25	DMF-Y-40S	DMF-Y-50S	DMF-Y-62S	DMF-Y-76S	DMF-Y-102S
Port sizes	G1''	G1 1/2''	G2''	G2 1/2''	G3''	G4''
Membrane sizes (φ66 smaller)	φ96	φ112	φ160	φ188	φ202	φ255
CV values	30.53	53.47	71.47	150.85	186.66	313.09
Blowing area (m2)	8-10	12-16	18-28	27-38	37-65	70-90
Weight (kg)	0.75	1.2	2.35	3.2	4.05	5.65
Environment Temperature	-25℃ to +80℃ or customized
Relative Humidity	≤85%
Working Medium	Clean Air
Protection Class	IP65
Service Life	Over one million times
Voltage	DC24V, AC24V, AC110V, AC220V

Tips: All related accessories are also sold, like Pulse Controller, Diaphragm Repair Kit, Solenoid Valve Coil and Solenoid Valve Armature Assembly.

List of All DMF Series BFEC Pulse Jet Valves:

Thread Valve	3/4''	1''	1.5''	2''	2.5''	3''	4''
Thread Valve	DMF-Z-20	DMF-Z-25	DMF-Z-40S	DMF-Z-50S	DMF-Z-62S	DMF-Z-76S	DMF-Z-102S
Quick Mount Valve	3/4''	Inlet φ27	1''		1.5''
Quick Mount Valve	DMF-ZM-20	DMF-ZL-B	DMF-ZM-25		DMF-ZM-40S
Flange Valve	1''			1.5''
Flange Valve	DMF-ZF-25			DMF-ZF-40S
Embedded Valve	1''	1.5''	Outlet φ62mm	Outlet φ75	Outlet φ89	Outlet φ114	Outlet φ102
Embedded Valve	DMF-Y-25	DMF-Y-40S	DMF-Y-50S	DMF-Y-62S	DMF-Y-76S	DMF-Y-102S	DMF-Y-102SA

Product Features:

1. Ready for use in any dust collector design
*For noxious substance control and environmental dust management

2. Cost savings
*Increased pulse efficiency, reduced energy consumption
*Durable materials and wide temperature range enhance lifespan
*Longer filter life, lower dust collector OPEX

3. Compliance
*With environmental and health & safety regulations

4. Ease of installation
*No welding required with 90° connections directly onto squaretanks
